Fold

Type Rigid

Working Widths

Spacing option A: Disc spacing – 22.86 cm, 9 in.
Option 1: 18 discs – 2.11 m
Option 2: 20 discs – 2.31 m
Option 3: 22 discs – 2.54 m
Option 4: 24 discs – 2.77 m
Option 5: 26 discs – 3.0 m
Option 6: 28 discs – 3.20 m

Transport Width

Spacing option A: 229 mm

Operating Speed

Km/h: 6.4 to 9.7 km/h

Power Requirements

Horsepower required: Power take-off – 29.8 to 74.6 kW | 40 to 100 hp
Engine – 35.8 to 89.5 kW | Light drawn – 18 discs 29.8, 20 discs 33.5, 22 discs 37.3, 24 discs 41.0, 26 discs 44.7, and 28 discs 48.5 kW | 18 discs 40, 20 discs 45, 22 discs 50, 24 discs 55, 26 discs 60, and 28 discs 65 hp | Medium drawn – 18 discs 41.0, 20 discs 44.7, 22 discs 47.5, 24 discs 52.2, 26 discs 55.9, and 28 discs 59.7
| 18 discs 55, 20 discs 60, 22 discs 65, 24 discs 70, 26 discs 75, and 28 discs 80
Heavy drawn – 18 discs 52.2, 20 discs 55.9, 22 discs 59.7, 24 discs 63.4, 26 discs 67.1, and 28 discs 74.6 | 18 discs 70, 20 discs 75, 22 discs 80, 24 discs 85, 26 discs 90, and 28 discs 100

Leveling Options

Option 1: Parallel-lift bar and 3-leaf spring for front-to-rear leveling and increased relative pressure on front or rear gangs

Depth Control

Option 1: Mechanical depth stops
Hydraulic Requirements

Standard: 1 selective control valve (SCV) required

Electrical Requirements

Standard: 9-pin connector for warning

Hitch

Type: Combination hitch with right or left offset options

Frame

Tubing: Structural steel – 4x4x3/406 mm

Gang

Angle: Adjustable
Front: 25 to 48 degree (angle)
Rear: 25 to 48 degree (angle)

Gang Tubing

Front: Structural steel – 3x5x3/406 mm
Rear: Structural steel – 3x5x3/406 mm
Gang bolt: Round – 38 mm
Gang standard: Rigid nodular iron
Bearings: Triple-sealed ball bearings with wear guards (no lubrication needed unless grease fittings are installed)
Scraper: Rigid

Finishing Blades

Option 1: Spherical blade with scraper – 356 mm
Middle breaker: Offset

Blades

Spacing: 229 mm

Blade Size

Option 1: Solid cone – 559 x 4 mm
Option 2: Solid cone or cutout cone, or a combination of a front cutout cone and a rear solid cone – 610 x 4.5 mm
Option 3: Solid spherical or cutout cone – 610 x 4.7 mm
Option 4: Solid cone or cutout cone – 610 x 6.5 mm

Wheels

Mainframe wheels and tires\
Option 1: 4PR rib implement base wheel and tire option – Two 15-5KB wheels with 6.70-15 in. 4PR rib implement tubeless tires (in base price)
Option 2: Wheels less tires options – Two 15-6 wheels less tires | Two 16-6 wheels less tires
Option 3: 6PR rib implement tubeless wheel and tire options – Two 14-6KB wheels with 9.50-14 in. 6PR implement tubeless tires | Two 15-6KB wheels with 7.60-15 in. 6PR implement tubeless tires
Option 4: 6PR rib implement tubeless wheel and tire option – Two wheels with 7.6-15 in. 8PR tires\

Wingframe wheels and tires

Option 1: At 152-cm (60-in.) wheel tread spacing, working width –
2.11 to 3.0 m
Option 2: At 203-cm (80-in.) wheel tread spacing, working width –
3.20 to 3.66 m
