KEY SPECS
Working widths: 13.1 in.43 ft
Spacing: Seed spacing – 254 mm10 in.Separate fertilizer – 508 mm20 in.
Number of ranks: Two seed ranks and one separate fertilizer rank
Openers: StyleSeed, ProSeries™ single-disk blade – 45.72 cm18 in.Fertilizer, single-disk blade – 45.72 cmRank lock-upFront, middle, and rearDiameter45.72 cm18 in.Down pressureHydraulic
SIZES
Working widths: 13.1 m43 ft
Spacing: Seed spacing – 254 mm10 in.Separate fertilizer – 508 mm20 in.
Number of ranks: Two seed ranks and one separate fertilizer rank
Number of sections: Three
DIMENSIONS
Transport height: 4.83 m15.83 ft
Transport width: 5.59 m18.33 ft
Road clearance: 21.59 cm8.5 in.
Overall length: 8.81 m28.92 ft
Centerframe width: 4.62 m15.17 ft
Centerline of mainframe wheel support tube to centerline of wing wheel support tubes
Weight before ballast: 14,100 kg30,900 lb
Available ballast: Main – up to 14 suitcase weights each at 45.4 kg100 lbEach wing – 6 suitcase weights each at 45.4 kg
Frame: Cross members102 x 152 mm4 x 6 in.End tubes51 x 152 mm2 x 6 in.Hitch76 x 152 mm3 x 6 in.
Lateral frame clearance, opener to opener
Clearance from rank to rank: 134.11 cm52.8 in.
From ground to top of lid
From ground to platform
From ground to top of safety rail
From ground to top of lights
TIRES
Mainframe standard: (8) 11L-15, I-1 12PR
Mainframe bolt pattern: Duals with eight-bolt wheels
Wings standard: (8) 11L-15, 10PR
Wings bolt pattern: Duals with six-bolt wheels
Centerframe tires and wheels
Wing tires and wheels
Wheel spacing, center frame
OPENERS
Style: Seed, ProSeries™ single-disk blade – 45.72 cm18 in.Fertilizer, single-disk blade – 45.72 cm
Rank lock-up: Front, middle, and rear
Disk: Diameter45.72 cm18 in.AngleSeed at 7 degree (angle)Fertilizer (dry only) at 5 or 7 degree (angle)Single blade with beveled edge
Down pressure: StyleActive hydraulic downforce10-in. space75 to 181 kg165 to 400 lbHydraulic
Depth control: DescriptionSemi-pneumaticGauge wheel sizeStandard – 11.43 x 40.64 cm4.5 x 16 in.Optional – 7.62 x 40.64 cm3 x 16 in.Range1.27 to 8.89 cm0.5 to 3.5 in.Increments0.64 cm0.25 in.Gauge wheel beside disk
In-Furrow press wheel: MaterialRubber-face press wheelPacking force2.3 to 21 kg5 to 45 lbTapered – 2.54 x 22.86 cm0.75 x 9 in.
Furrow closing: DescriptionTrailing wheel on vertical 15 degree (angle)Size2.54 x 30.48 cm1 x 12 in.MaterialCast ironDown force12 to 20 kg26 to 43 lbYes
Double-Shoot capable: Yes – front ranks apply fertilizer
SEED METERING
Description
Crops
Max Volumetric Seeding Rates – Barley
Max Volumetric Seeding Rates – Oats
Max Volumetric Seeding Rates – Rice
Max Volumetric Seeding Rates – Milo/Sorghum
Max Volumetric Seeding Rates – Soybean
Max Volumetric Seeding Rates – Wheat
Metering Drive Type
SEED STORAGE
Tank Description
Total Tank Capacity
Tank Fill Screen
Tank Scales
Seed Distribution
Type
Blower
Blower drive type
Distribution hose size
EQUIPMENT COMPATIBILITY (AT 1.5 IN. SEEDING DEPTH AND 8 MPH)
Tractor drawbar power required, 7.5-in (19.1 cm) models
Tractor drawbar power required, 10-in (25.4 cm) models
Tractor drawbar power required, 15-in (38.1 cm) models
TRACTOR REQUIREMENTS
Minimum number of SCV’s
Hydraulic Power Beyond
Minimum hydraulic capacity
Minimum electrical capacity
ADDITIONAL INFORMATION
Tool-mounted alternator
Implement harness connection, 56 VDC
Implement harness connection, 12 VDC
Operator interface
Four-section seed on/off
Fast start/Quick start
Seed blockage sensor per row
Date collected
