WEIGHT AND POWER

Approximate weight without fertilizer, seed and agrochemicals\: 2 Rows: 494 kg (1089.1 lb) 3 Rows: 699 kg (1541.0 lb) 4 Rows: 1049 kg (2312.6 lb)
Approximate weight with fertilizer, seed and agrochemicals: 2 Rows: 802 kg (1768.1 lb) 3 Rows: 1161 kg (2559.6 lb) 4 Rows: 1666 kg (3672.9 lb)
Power required at PTO* (PTO: Power take-off): 2 Rows: 53 Hp 3 Rows: 67 Hp 4 Rows: 83 Hp

MAIN FRAME

Dimensions of the RHS: Rectangular Hollow Section (RHS) of 12.7 x 17.8 cm (5 x 7 inches)
Length of the RHS: 2 Rows – Optional: 2.50 m (98.4”) 3 Rows – Basic: 2.50 m (98.4”) – Optional: 3.50 m (137.8”) 4 Rows – Basic: 3.50 m (137.8”) – Optional: 3.50 m (137.8”)
Markers: 2 Rows: – 3 Rows: – 4 Rows: Optional
Drive wheel: 2 Rows: 1 3 Rows: 1 4 Rows: 2

SEEDING SYSTEM

Capacity and material of seed bin: 40 L (10.6 gal) / High-density polyethylene (HDP)
Planting system: 2 Rows – Mechanical finger: Basic – Cell plate mechanism: Optional 3 Rows – Mechanical finger: Basic – Cell plate mechanism: Optional 4 Rows – Mechanical finger: Basic – Cell plate mechanism: Optional\
Seed trench: Double disk and blade
Steel cleaners for heavy work: Basic, rigid steel cleaners with tension spring
Cleaners for heavy work: Optional
Steel cleaners: Options, shield-type cleaners, double disk, rigid steel cleaners
Seed covering system: – Press wheel or semi-pneumatic compactor: Basic – Cover disks: Optional – Cover blades: Optional – Chains: Optional

FERTILIZER SYSTEM

Capacity and material of fertilizer bin: 70 L (18.5 gal.) / High-density polyethylene (HDP)
Fertilizer: Dry granular (basic)
Dosing system: Auger and gears
Fertilizer spreading: – Air distribution of fertilizer: Basic – Front disks in “V” arrangement to the side 5 cm from the seed and 5 cm deep: Optional – Skid or opening blade for conventional planting: Optional

INSECTICIDE SYSTEM

Capacity and material of insecticide bin: 16 L (4.2 gal.) / High density polyethylene (HDP)
Insecticide type: Microgranulated (basic)
Dosing system: With gears, gate regulator knob and cylinder mechanism with blades

MISCELLANEOUS

Computer Track 150 Seed Monitor: Optional
