KEY SPECS
Number of rows: 24 or 26 (Available from factory)
Row spacing: 24 rows: 50 cm 19.7 in. 26 rows: 45 cm 17.7 in.
Row unit seed hoppers: Central Commodity System (CCS™)
Capacity: Total 2.270 L 64.4 bu
Seed Meters:
Base: MaxEmerge™ 5
ROWS AND ROW SPACING
Number of rows: 24 or 26 (Available from factory)
Row spacing: 24 rows: 50 cm 19.7 in. 26 rows: 45 cm 17.7 in.
TIRES
Base: 7.00 16 10 PR
Quantity: Eight
ROW UNITS
Type: EmergePro™ row-unit Planting Row with Gauge Wheels Away
Opener: Tru-Vee seed opener disks
Depth gauging: Gauge Wheels
Adjustment: T-handle
Row unit seed hoppers: Central Commodity System (CCS™)
Capacity: Total: 2,270 L 64.4 bu
Material: Polyethylene
Row unit down force: Yes
Mechanical: Spring – Available for MaxEmerge™ 5
Seed tube sensors:
Base: Yes
SEED METERS
Base: MaxEmerge™ 5
DRIVE SYSTEM
Base: Mechanical Electrohydraulic
Optional: SeedStar™ 2
Seed transmission: Pro-shaft™ drive (MaxEmerge™ 5)
MARKERS
Type: Hydraulic (optional)
CLOSING SYSTEM
Rubber tire closing system: Yes
Adjustment: T-handle
FERTILIZER
Fixed-rate application: Yes
Variable-rate application: Yes with Electrohydraulic transmission
Fertilizer opener type: Pantographic Multi-furrow – Hoe-type and double-disk Pivoted Multi-furrow – Hoe-type and double-disk
Dry fertilizer:
Number of hoppers: Six
Hopper capacity: 4950 L 1307.7 gal.
Fertilizer meter types: ProMeter™
DIMENSIONS
Transport width (with markers): 13.2-13.7 m 43.31-44.95 ft
Transport width (without markers): 12.6-13.1 m 41.34-42.98 ft
Transport length: 6 m 24.6 ft
Transport height: 2.5 m 8.2 ft
Transport weight: 13100 kg 31085 lb
AG MANAGEMENT SOLUTIONS
Map-based seeding: Yes
Field documentation: Yes
ADDITIONAL INFORMATION
Recommended tractor horsepower: 260-320 cv 256.4-315.6 hp Note: The required tractor power values are variable and depend on numerors factors, such as planting speed, planting depth, and soil conditions, among others.
2126 Drawn Planter
The 2126 Planter provides better performance in irregular, clay and straw soils. It attaches to the tractor drawbar. Furthermore, it is available in 24 and 26 rows configurations.
• 25 percent less ground disturbance with the 2100 pivoted multi-opener
• 23 percent better control of seed placement due the combination of the EmergePro™ row-unit with the 2100 pivoted multi-opener
• 16 percent better plant stand
• 8 percent more fuel savings since the 2100 pivoted multi-opener requires less tractor power
• 7 percent more seed savings with the RowCommand™ system
• 3 percent more fertilizer savings with Section Control
• Increased control of operation with the variable rate of seed and fertilizer
-
