BALE DIMENSIONS
Bale: 90×120 cm 3×4 ft
Width: 120 cm 46.5 in.
height: 90 cm 35 in.
Length: 60 up to 300 cm 24 up to 118 in.
PICKUP
Intake width: Standard: 220 cm 86 in. Optional: 250 cm 97 in.
Pickup diameter: 25.6 cm 10 in.
Number of tine bars 4-5: Four
Tine spacing: 6.6 cm 2.6 in.
BALE CHAMBER
Number of plunger strokes: 45 spm
Plunger stroke: 69.5 cm 27 in.
Density control: Four hydraulic cylinders
Bale chamber length: 305 cm 120 in.
Control: 600/50/22.5 or 710/40R/22.5
KNOTTING SYSTEM
Number of knotters: Six
Twine capacity (rolls): 30
INTAKE SYSTEM
High-capacity rotor: Yes
Knives: 21, 11, or 10
Cutting length: 44 mm 1.7 in. or 88 mm 3.5 in.
Knife protection: Individual spring
Slide out floor: Yes
WHEELS AND AXLES
Single axle: 600/50/22.5 or 710/40R/22.5
Tandem axle steered (optional): 500/55/20 or 550/45/22.5
Brakes system: Optional hydraulic
MACHINE DIMENSIONS
Length: 8.0 m 26.25 ft
Width: 3.0 m 9.8 ft
Height: 2.75 m 9 ft
Weight: 9,210 kg 20,370 lb
Minimum tractor requirement: 108 kW 145 PTO hp
Large Square Baler L341
• 2.2m MegaWide™ pickup for better shaped bales and improved crop pickup in wide, windblown, or scattered windrows.
• Optional 2.5m Premium MegaWide™ pickup, tooth-to-tooth, is the widest in the industry.
• Designed by John Deere, the moisture sensor is the industry’s most accurate across the full range of moisture levels.
• BalerAssist™ drivetrain system option allows you to hydraulically back out plugs with a remote.
• Optional 21-knife precutter has a drop floor that slides out for easier access and maintenance.
-
• 260 hp
• Integrated AutoTrac™ steering system helps maintain crop quality even at faster cutting speeds
• JDLink™ enabled
• TouchSet™ for in cab adjustments
• Transport speed up to 24 mph -
• 13 ft. (4 m) cut width
• Compatible with W200M and W235M
• Impeller, Urethane or V10 conditioning options
• Quick Change Knives -
Vegetables are rich in many vitamins and minerals that are good for your health. These include vitamins A (beta-carotene), C and E, magnesium, zinc, phosphorous and folic acid.
Vegetables nutrients help reduce obesity, lower cholesterol and lower your blood pressure.
-
• Shim for application equipment
• Note: This product is returnable only if it returned in its original packaging and has not been installed. -
• Hydr. Quick Coupler Socket for Tractor hydraulics
• Note: This product is returnable only if it returned in its original packaging and has not been installed.
- Engine: 55 HP, 2400 RPM, 3 Cylinders, Coolant cooled with overflow reservoir, Turbo charged
- Air Filter: Dry type, Dual element
- Transmission: 9 Forward + 3 Reverse speed, Collarshift Gearbox
- Hydraulics: Lifting Capacity 1800 kgf at lower link ends
Main applicable crops: Wheat, soybean, rape, sorghum, millet, etc.
Cutting width (m): 4.57 or 5.4
Feeding amount (kg/sec): Wheat: 7.0 (4.57 meters cutting header); 8.0 (5.4 meters cutting header)
Ground clearance (m): 0.495
Threshing drum type: Patterned
Roller width×diameter (m): 1.28×0.61
Separation mechanism type: Five-button document stepper
Separation area (square meters): 5.38
Type of cleaning organization: Double-layer vibrating wind screen
Cleaning area (square meters): 4.3
Grain tank volume (m3): 4.6
engine model: JD6068
Engine power (hp/kw): 185/136
Dimensions (length × width × height, meters): 7.13×3.26×3.84 (transport size without header)
Structure mass (kg): 7190 (without header without chopper)
Walking speed (km/h) Mechanical: 1.05-20 (forward gear) 2.30-5.55 (reverse gear) Hydraulic pressure: 0-24
Front wheel track (m): 2.8
Rear wheel track (m): 2.57
Air Conditioning: Optional heating and cooling air conditioning
Option Wheat accessories, corn accessories
- 9 l PowerTech PSS engine, 285 kW/387 hp max Power (ECE R120)
- Channel width 1,400 mm
- Total active separation area (ISO 6689:1997): 3.30 m²
- Total cleaning shoe area (with front chaffer according to ISO 6689:1997): 5.20 m²
- Interactive Combine Adjust (ICA) automatic combine optimisation.
- New John Deere Tracks with 30% bigger footprint
- Power Steering
- Dry Air Cleaner
- Oil Immersed Disk Break
- Collar Shift Gear Box
- Top Shaft Lubrication
- Piston Cooling Jet
• Struck capacity 10.7 m³ (14 cu. yd.)
• Heaped capacity 16.4 m³ (18 cu. yd.)
- Struck capacity 10.7 m³ (14 cu. yd.)
- Heaped capacity 16.4 m³ (21.5 cu. yd.)
- Struck capacity 11.1 m³ (14.6 cu. yd.)
- Heaped capacity 15.3 m³ (20.0 cu. yd.)
- Bowl width 4.4 m (14 ft. 6 in.)
- Struck capacity: 10.4 m³ (13.6 cu. yd.)
- Heaped capacity: 15.3 m³ (20.0 cu. yd.)
- Bowl width: 3.2 m (10 ft. 6 in.)
- 9 l PowerTech PSS engine, 285 kW/387 hp max Power (ECE R120)
- Channel width 1,670 mm
- Total active separation area (ISO 6689:1997): 4.00 m²
- Total cleaning shoe area (with front chaffer according to ISO 6689:1997): 6.30 m²
- Interactive Combine Adjust (ICA) automatic combine optimisation.
- New John Deere Tracks with 30% bigger footprint
Simple and reliable – with its robust quality and great versatility, this tractor is made to meet your needs: an uncomplicated machine that can withstand the hardest loads yet is still attractively priced.
- John Deere PowerTech 4.5 L Engine,powerful,fuel-efficient, reliable, maintenance friendly.
- Configured with John Deere Gearbox, high-efficiency and easy operation.
- The driver’s cab,with a superlative visual field, is spacious and comfortable with good seal performance and low noise.
- The hydraulic system is stable and reliable, fuel tank capacity was increased to 150 L.
POWER AND TECHNOLOGY
- 230HP Power.
- New power ratings and increased technology to make your business more productive.
- Excellent performance for heavy work, with low fuel consumption.
- Excellent performance, from transport to soil preparation.
- Technology features included as standard: John Deere Engine with Common Rail electronic injection; two transmission options: PowrQuad Plus™ and AutoQuad™
- AutoQuad™: changes gear automatically, in accordance with engine load and the front axle option with Triple Link Suspension (TLS).
