Main applicable crops: Wheat, soybean, rape, sorghum, millet, etc.
Cutting width (m): 4.57 or 5.4
Feeding amount (kg/sec): Wheat: 7.0 (4.57 meters cutting header); 8.0 (5.4 meters cutting header)
Ground clearance (m): 0.495
Threshing drum type: Patterned
Roller width×diameter (m): 1.28×0.61
Separation mechanism type: Five-button document stepper
Separation area (square meters): 5.38
Type of cleaning organization: Double-layer vibrating wind screen
Cleaning area (square meters): 4.3
Grain tank volume (m3): 4.6
engine model: JD6068
Engine power (hp/kw): 185/136
Dimensions (length × width × height, meters): 7.13×3.26×3.84 (transport size without header)
Structure mass (kg): 7190 (without header without chopper)
Walking speed (km/h) Mechanical: 1.05-20 (forward gear) 2.30-5.55 (reverse gear) Hydraulic pressure: 0-24
Front wheel track (m): 2.8
Rear wheel track (m): 2.57
Air Conditioning: Optional heating and cooling air conditioning
Option Wheat accessories, corn accessories

• The feed rate has been increased to 9 kg per second, equipped with a newly upgraded threshing separation device, which is superior to the same level
• The newly optimized grid intaglio works perfectly with the new drum to ensure that the grains are separated from the material flow quickly and efficiently
• Equipped with John Deere 165 horsepower 4045 turbocharged with high pressure common rail electronic control engine, high reliability and good fuel economy
• Increase the fuel tank volume up to 300 liters, 4.2 cubic meters super large grain tank, unloading speed of 36 liters per second
